Hammerglass®
Driver safety is becoming more recognized as a key issue in the mining and construction industries. Accidents happen and when they do they tend to have life changing or even fatal consequences. Hammerglass's unbreakable windows and glass is providing a real solution to this industry challenge and has proven to be a life saver.
​
Not only is Hammerglass a life-saver it's a money saver with a comprehensive range of virtually unbreakable screens for all types of construction machinery, with the focus on a safer driver environment.
​
The material with its abilities gives an outstanding cost efficiency since the owner avoids production stops due to unforeseen changes of broken and worn screens
​
-
World class driver protection - 300 times stronger than glass
-
Superior operating economy without glass breakage
-
Explosion tested alternatives for the toughest environments
-
Light weight construction
-
Effective anti-scratch solutions
-
Improved cabin comfort with heat reducing IR glass
-
Grid free cabins with free sight
-
Available for most models on the market
-
Certified ECE R43 Rigid Plastic Windscreens
300 Times Stronger than Glass
Hammerglass offers world class driver protection - 300 times stronger than glass. Made from a durable and wear-resistant polycarbonate sheet Hammerglass is virtually unbreakable
​
Hammerglass 12 mm in a steel frame satisfies the RABS requirements of
​
R43 - ECE Regulation No.43 (R43). A comprehensive series of tests for vehicle glass, including scratch protection, UV protection and elongation
​
AXE - Sharp object (EN 356, P8B), a test in which the screen withstands 72 blows from a machine-mounted axe, without the axe penetrating the glass.
​
BLAST - Pressure wave upon detonation (EN 13124-2, EXR 2), a test in which 3 kg (6.6 lbs) TNT are detonated at a distance of 3 meters (9.8 feet)
​
STONE - Heavy objects at high speed (EN 15152-2), a test in which a 1 kg (2.2 lbs)aluminium projectile is propelled against the screen at a speed of 450 km/h (280 mph) and at an angle of 90 degrees thereto. Equivalent to a large rock propelled at high speed.
Scratch Resistant
OEM windscreens get scratched by the windscreen wiper in normal mining and construction operating environments.
​
Hammerglass screens are coated with a thin layer of silicon oxide which protects against scratches and wear and tear. In sand-filled environments, however, we recommend that a ScreenSaver film is applied to the screen.
​
Nanotechnological surface treatment renders Hammerglass resistant to most chemicals - which enables simple graffiti removal, and helps to prevent pollutants from exhaust fumes, oil and asphalt from adhering to Hammerglass as easily as to ordinary glass. The surface treatment also provides 99.96% UV protection, which means the material will not cloud, discolour or undergo any other change in optical quality over time. Hammerglass does not contribute to the spreading of flames in the event of fire.
Explosion Resistant - RABS Approved
Undetonated explosives (duds), large rocks and boulders may pose a direct threat to the life of the machine driver. Where there is a risk of undetonated explosives being encountered, or where quarrying is in progress, Hammerglass should be used in the machine cab.
​
A series of tests in accordance with EN 13124-2 has been conducted on Hammerglass vehicle screens. Screens in a number of designs were mounted in various types of steel frames. Seven explosions were carried out, at a distance of 3 metres and 5 metres respectively. As a result it was demonstrated that 12 mm Hammerglass screens in steel frame withstand the pressure wave generated by 3 kg TNT being exploded at a distance of 3 metres
Operator Benefits
Hammerglass® offers a number of benefits to machine operators that improves their overall workplace environment whilste offering the peace of mind of maximum safety and ability to operate more effectively.
Solar Heat reduced by half
Hammerglass IR (Infrared) removes 45-55% of the incoming solar radiation. The screens are supplied in tinted Hammerglass IR.
​
Hammerglass IR absorbs the sun’s infrared rays (heat radiation) without any appreciable reduction in the light transmission (approximately 10%)
A cooler cabin with less solar heat exposure is a more pleasant environment to operate in.
Grid Free Clear Vision
"Get rid of the grid"
The Hammerglass Guard solution gives you a complete driver protection that will withstand both explosions and stone projectiles.
Meanwhile, the driver has a clear view and does not have to look through grid during their work day.
​
Having a clearer unhampered vision is an additional safety feature.
Safe Cabin
The machinery operator should feel safe even if incidents should happen. The patented Hammerglass Guard system has been developed with a focus on maximising personal safety in tough environments.
​
A front window guard only protects from the front. Hammerglass protects the machine all around, and contributes to a much safer working environment.
Reduced Diesel Costs
Hammerglass IR screens cut the Solar Heat by 45-55% over traditional OEM glass. This reduction of incoming solar radiation means that the air-conditioning systems are able to operate more effectively.
Some operators in Europe have noticed savings of $1000's per machine per annum against the exact same machine doing the same job without Hammerglass IR screens fitted.
Save Money on Replacements
As we know that production stoppages are costly and time consuming. Having Hammerglass unbreakable screens installed you provide a secure working environment with fewer operational disruptions.
​
The frequency and cost of machine downtime is reduced saving $1000's in operational cost.
Extend Screen Life
Hammerglass-screens can be provided with an additional self-adhesive ScreenSaver protective film, which the driver can replace as and when required.
​
Hammerglass ScreenSaver protective film is an invisible self healing shield that is reducing wear, scratches and marks from stone chips on your Hammerglass screen. When you use the protective film, the life of the window is extended while the optical quality is ensured.
